Digital Cable Remote (Atlas) Support

How do I program my Atlas remote control?

1. Turn on the electronic device (TV, DVD, AUDIO) you want to program the remote to operate.
2. Open the Atlas code list and find the possible codes for the device you want to control. (Please refer to the attachment at the bottom of this article.)
3. On the remote, press the corresponding button to the device you’re programming, such as TV, DVD, AUD, or CBL one time. It will blink once.
4. Press and hold [SETUP] until the selected device button on the remote (such as TV) blinks twice.
5. Enter the 4-digit code for your device’s manufacturer. The selected device key should blink twice.
6. Point the remote at the device and press [MASTER POWER] once. If the device turns off, it means the code has been accepted. Turn the device back on and make sure the remote controls it.
7. If the code did not work, repeat steps 3 through 6 with each of the manufacturer’s codes for your device until one is successful.
8. Repeat the above steps for each of the remaining electronic devices you wish to program the remote to operate.
9. Press [CBL] to set the remote to Cable Mode. If the remote is not in Cable Mode, buttons such as Guide, Info, etc., will not function.

I tried all the codes available and the remote did not program. What do I do now?

If the available codes do not program your remote, please try the search method:

1. Turn on the electronic device (TV, DVD, AUDIO) you want to program the remote to operate.
2. On the remote, press the corresponding button to the device you’re programming, such as TV, DVD, AUD, or CBL one time. It will blink once.
3. Press and hold [SETUP] until the selected device button on the remote (such as TV) blinks twice.
4. Enter the code 9-9-1. The selected device button should blink twice.
5. Press the [MASTER POWER] button once.
6. Press the [CH+] button repeatedly, one press at a time, until the device turns off.
7. Press [MASTER POWER] to turn the device back on.
8. Press [SETUP] to lock in the code.
9. Press [CBL] to set the remote to Cable Mode. If the remote is not in Cable Mode, buttons such as Guide, Info, etc., will not function.

How do I program the Master Power button to power all my devices on or off?

If you do not program the [MASTER POWER] button, pressing it will only turn your cable box on or off. In any other mode, such as TV or AUD, pressing [MASTER POWER] once will turn the selected device on or off.

To program the button to turn all your devices on or off, please try the following steps:

1. On the remote, press and hold [SETUP] until the most recent selected device button (such as CBL, TV, AUD, etc.) blinks twice.
2. Enter the code 9-9-5. The last-selected device key blinks twice.
3. Press [MASTER POWER] one time.
4. For the first device you want in the power-on sequence, press a device key (such as CBL).
5. Press [MASTER POWER] one time.
6. For the next device in the power-on sequence, press the corresponding device key (such as TV).
7. Press [MASTER POWER] one time.
8. Repeat steps 4 through 7 to add additional device keys if desired.
9. To save these settings and exit programming mode, press [CBL] one time, and then press and hold [SETUP] until the [CBL] button blinks twice.

Please note: After programming, the [MASTER POWER] button will only turn off all devices while the remote is in Cable Mode.

Help! Certain buttons do not work on my remote.

If buttons such as Guide, Info, Exit, Page+ and Page-, the arrow keys, A/B/C, or Last do not respond, please make sure the remote is in Cable Mode. To do so, press [CBL] one time.

Please note: The Settings button will not display the cable settings menu. To access those settings, press the [MENU] button.

Atlas Remote Programming Codes
